handheld laser welding machine for stainless steel

This is 1000 watts Raycus fiber laser welding machine with CW laser source.(1500W/2000W optional)
-Fast welding speed
-Prefect welding effect
-100,000 hours lifetime
-No any consumable part

  • OPT-FW1000/1500/2000
  • OPTIC
  • Fiber laser welding machine
Quantity:

Fiber Handheld Laser Welding Machine Product parameters Description

1000W 1500W 2000W Raycus IPG Fiber Handheld Laser Welding Machine



Handheld Laser Welding Machine Specifications


Laser power 1000/1500/2000 watts
Laser source
Raycus / IPG
Welding head
Wobble welding head / Normal welding head
Laser frequency
50Hz-5000Hz
Adjustable power rate
5 to 100%
Beam quality  1.1
Electric power
220V50HZ / 380V 50Hz
Wavelength
1070±5nm
Consumable part
Protection lens,focusing lens nozzle
Fiber leangth
15m Standard
Cooling method

Water chiller

Dimension
930x600x800mm
Gross weight
200kg

Handheld Laser Welding Machine Fiber laser source



Raycus laser machine

Back of the Laser Machine



The third-generation single module CW fiber laser series developed by Raycus ranges from 300W to 2,000W,

 the new lasers has higher electro-optical conversion efficiency, higher and more stable optical quality,

stronger altitude stress-resisting capacity and it applies optimized second-generation fiber transmission

system to ensure more  stable and more sophisticated cutting effect in thick sheet cutting. This machine

applies to many application scenarios: cutting, welding, holing, medical device processing, etc., with a

narrow seam of the cut sheet and bright section. Compared with same lasers, it has obvious advantages.


Welding head with wobble function.

Why need the wobble welding head for fiber laser welding machine?


Head for fiber laser welding machine


The advantage of laser welding wobble head


1. The process that the conventional head can not complete, the dithering head only needs to use about

    70% of the power, so that the cost of the laser can be saved;


2 Wobble welding back and forth through the galvanometer motor, so that the bubbles with large impurities

  can reduce bubbles, frying, splashing, etc.


3 In the case of irregular gaps, the requirements for the fixture can be reduced.

   The conventional oscillating head welding gap is generally 0.2 mm, and light exceeding this width directly

   passes through. The width of the gap that can be welded by the oscillating head can reach 0.5mm,

   but the conventional welding head can only be welded to 0.2mm. There is no galvanometer motor in

   the welding head, so there is no swing. The welding effect is not good, the welding process is limited.




Safety Protection device for 1kw Fiber Handheld Laser Welding Machine

Safety Protection device for 1kw fiber  handheld laser welding machine

Safety Protection device

The red part with black color is protection device when the machine welding on metal.

If the safety device didn't clamp what do you weld metal,the laser power can not coming.

So it have to clamp the metal as you welding that one. The laser power can coming out.


Water chiller and laser source with inside one cabinet

Water chiller and laser source with inside one cabinet

Water chiller

Water chiller provide good cooling system for the laser source and welding head. It can protect source and

welding head working long time per day.Maximum can up to 10 hours per day.

Also can help you save more layout space and shipping cost.


The complete fiber laser welding machine easy to move and one wood box

Handheld Laser Welding Machine For Stainless SteelFour-wheeled

Four wheel with the machine and easy to move where do you need.
